Motor Yamaha PW-ST System, 250W, 70Nm, 25km/h
Display Yamaha Side Switch
Akku / Battery Yamaha Lithium Ion 500Wh
Ladegerät / Charger Yamaha quick charger 4A
Rahmen / Frame aluminium 6061, quick-release 5 x 135mm, disc brake
Post Mount
Gabel / Fork RockShox Recon TK Remote Lockout, steel spring,
Travel: 100mm, steel steerer tube 1 1/8", quick release
Umwerfer / Front derailleur Shimano Deore M6000
Schaltwerk / Rear derailleur Shimano Deore M6000, 20-speed
Schalthebel / Shift lever Shimano Deore M6000, rapidfire
Zahnkranz (hinten) / Sprocket Shimano HG500, 11-42 teeth
Kette / Chain KMC e10S
Kettenblatt / Chainring aluminium, FSA, 44-32
Bremshebel / Brake lever Shimano MT401, aluminium
Bremse vorne / Brake front Shimano MT400, aluminium, 180mm
Bremse hinten / Brake rear Shimano MT400, aluminium, 180mm
Reifen / Tyres Schwalbe Smart Sam, 57-622
Felgen / Rims Rodi Black Rock 21, eyed, double-walled rim,
aluminium
Vorderradnabe / Front wheel hub Shimano MT400-B
Hinterradnabe / Rear wheel hub Shimano TX505-8
Speichen / Spokes Sapim Leader, black
Lenker / Handlebar Haibike Components TheBar+ 740mm
Griffe / Grips Haibike MTB grips
Vorbau / Stem Haibike Components The Stem +, A-head
Steuersatz / Headset A-Head Tapered
Sattel / Saddle Haibike Components TheSaddle
Sattelstütze / Seat post Haibike Components The Seatpost +, patent,
31.6mm, aluminium
Pedale / Pedals Freeridepedal aluminium, mit Reflektor
Zul. Gesamtgewicht / Permitted
total weight
120kg
Bicycle type MTB Hardtail
- Moottori: Yamaha PW-ST System, 250W
- Vääntö: 70Nm, 25km/h
- Näyttö: Yamaha Side Switch
- Akku: Yamaha Lithium Ion 500Wh
- Runko: aluminium 6061, quick-release 5 x 135mm, disc brake
Post Mount - Haarukka: RockShox Recon TK Remote Lockout, steel spring,
Travel: 100mm, steel steerer tube 1 1/8", quick release - Vanteet: Rodi Black Rock 21, eyed, double-walled rim,
- Vaihteisto: Shimano Deore M6000, 20-speed
- Vaihdekahva: Shimano Deore M6000, rapidfire
- Kasetti: Shimano HG500, 11-42 teeth
- Ketju: KMC e10S
- Eturatas: Chainring aluminium, FSA, 44-32
- Jarrukahva: Shimano MT401, aluminium
- Jarrulevy edessä: Shimano MT400, aluminium, 180mm
- Jarrulevy takana: Shimano MT400, aluminium, 180mm
- Renkaat: Schwalbe Smart Sam, 57-622
- Etupyörän napa: Shimano MT400-B
- Takapyörän napa: Shimano TX505-8
- Ohjaustanko: Haibike Components TheBar+ 740mm
- Kahvat: Haibike MTB grips
- Ohjainkannatin: Components The Stem +, A-head
- Ohjainlaakeri: A-Head Tapered
- Satula: Haibike Components TheSaddle
- Satulaputki: Haibike Components The Seatpost +, patent, 31.6mm, aluminium
- Polkimet: Freeridepedal aluminium, mit Reflektor
- Sallittu enimmäispaino: 120,00 kg
Motor Yamaha PW-ST System, 250W, 70Nm, 25km/h
Visa Yamaha sidobrytare
Akku / Batteri Yamaha Lithium Ion 500Wh
Ladegerät / Laddare Yamaha snabbladdare 4A
Rahmen / Ram aluminium 6061, snabbkoppling 5 x 135 mm, skivbroms
Stolpfäste
Gabel / Gaffel RockShox Recon TK Fjärrlåsning, stålfjäder,
Slaglängd: 100 mm, styrrör i stål 1 1/8", snabbkoppling
Umwerfer / framväxel Shimano Deore M6000
Schaltwerk / Bakväxel Shimano Deore M6000, 20-växlad
Schalthebel / Växelspak Shimano Deore M6000, rapidfire
Zahnkranz (hinten) / Kedjehjul Shimano HG500, 11-42 tänder
Kette / Kedja KMC e10S
Kettenblatt / Kedjering aluminium, FSA, 44-32
Bremshebel / Bromsspak Shimano MT401, aluminium
Bremse vorne / Broms fram Shimano MT400, aluminium, 180mm
Bremse hinten / Broms bak Shimano MT400, aluminium, 180mm
Reifen / Däck Schwalbe Smart Sam, 57-622
Felgen / Rims Rodi Black Rock 21, eyed, dubbelväggig fälg,
aluminium
Vorderradnabe / Framhjulsnav Shimano MT400-B
Hinterradnabe / Bakhjulsnav Shimano TX505-8
Speichen / Spokes Sapim Leader, svart
Lenker / Styre Haibike Components TheBar+ 740mm
Griffe / Grips Haibike MTB-grepp
Vorbau / Stem Haibike Components The Stem +, A-huvud
Steuersatz / Headset A-Head Tapered
Sattel / Sadel Haibike Components Sadeln
Sattelstütze / Sadelstolpe Haibike Components Sadelstolpen +, patent,
31,6 mm, aluminium
Pedal / Pedaler Freeridepedal aluminium, med reflektor
Zul. Gesamtgewicht / Tillåtet
totalvikt
120 kg
Cykel typ MTB Hardtail
- Motor: Yamaha PW-ST System, 250W
- Vääntö: 70Nm, 25km/h
- Näyttö: Yamaha Side Switch
- Akku: Yamaha Lithium Ion 500Wh
- Runko: aluminium 6061, snabbkoppling 5 x 135 mm, skivbroms
Stolpfäste - Haarukka: RockShox Recon TK Remote Lockout, stålfjäder,
Slaglängd: 100 mm, styrrör i stål 1 1/8", snabbkoppling - Vanteet: Rodi Black Rock 21, eyed, dubbelväggig fälg,
- Tillbehör: Shimano Deore M6000, 20-växlad
- Vaihdekahva: Shimano Deore M6000, rapidfire
- Kasetti: Shimano HG500, 11-42 tänder
- Ketju: KMC e10S
- Eturatas: Kedjering aluminium, FSA, 44-32
- Jarrukahva: Shimano MT401, aluminium
- Jarrulevy edessä: Shimano MT400, aluminium, 180mm
- Jarrulevy takana: Shimano MT400, aluminium, 180mm
- Renkaat: Schwalbe Smart Sam, 57-622
- Etupyörän napa: Shimano MT400-B
- Takapyörän napa: Shimano TX505-8
- Ohjaustanko: Haibike Components TheBar+ 740mm
- Kahvat: Haibike MTB-grepp
- Ohjainkannatin: Komponenter The Stem +, A-huvud
- Ohjainlaakeri: A-huvud avsmalnande
- Satula: Haibike Components Sadeln
- Satulaputki: Haibike Components Sadelstolpen +, patent, 31,6 mm, aluminium
- Polkimet: Freeridepedal aluminium, med reflektor
- Sallittu enimmäispaino: 120,00 kg
