The Monsterlux Level Guard LED flashing beacon / warning light is an extremely compact, low-profile yellow warning light for vehicles and machinery where installation space is limited. Despite its small size, it offers high visibility and is suitable for professional use even in demanding conditions.
The light has five different flashing modes, allowing visibility to be tailored to the specific application. R65 approval permits its use as a warning light in road traffic. Its compact design makes it an excellent choice for, for example, vans, lorries, tractors, forestry machinery, excavators, all-terrain vehicles and other work vehicles. A high IP rating and a durable aluminium construction ensure reliable operation throughout the year.
The light can be mounted, for example, on the roof, on parts of the chassis or in other low-profile mounting locations. Note: Always fit the Monsterlux logo facing upwards to ensure that the vent is pointing downwards. R65 approval allows for use as a warning light in road traffic in accordance with regulations.
Technical specifications
• Product number: 3555-301501
• Make and model: Monsterlux Level Guard
• Light colour: Yellow
• Operating voltage: 9–36V
• Approvals: CE, R10, R65, XA1, RoHS
• IP rating: IP68 / IP69K
• Connector type: Deutsch DT 3-pin.
• Mating connector: Yes
• Cable length: 35 cm + 15 cm mating connector
• Dimensions: 90 x 16 x 49 mm (Width|Height|Depth) ((Height including base: 25 mm))
• Weight: 0.2 kg
• LEDs: 8 x 4W LEDs
• Body material: Aluminium
• Warranty (months): 12
