The Monsterlux Core 9 is a striking 9-inch round LED auxiliary light with modern dark optics and a black housing. It combines a long range, a wide beam pattern and pleasant light for everyday driving. Carefully designed optics and road approval make it a safe and stylish choice for both passenger cars and commercial vehicles.
The Core 9 offers a balanced light pattern that combines good range with wide lateral visibility. The 5000 K colour temperature ensures clear contrast even in snow, rain and darkness. Monster Mode™ unlocks the headlamp’s full performance for off-road use. The stylish white and orange parking light completes the look and improves visibility. The robust body, hard-coated lens and sealed construction are designed to withstand water, salt, vibration and freezing temperatures.
Installation is quick and neat thanks to the pre-fitted Deutsch DT 2-pin connector. The sturdy bottom mounting and support points at the rear of the body reduce vibration and ensure a stable installation even in challenging conditions. Monster Mode is intended for off-road use only and is not approved for use on public roads.
Technical specifications
- Product number: 3550-901001
- Make and model: Monsterlux Core 9, black body
- Lumens: 4,523 lm (E-approved measurement) 9,600 lm (Monster Mode measurement)
- Beam range: 436 m (E-approved) 667 m (Monster Mode)
- Colour temperature: 5000 K
- Current consumption at 13.7 V: 3.67 A (E-approved) 12.82 A (Monster Mode)
- Operating voltage: 9–36 V
- Power: 50.2 W (E-approved) 175 W (Monster Mode)
- Reference number: 45
- Parking light: Yes, white and orange
- Road-legal: Yes
- Approvals: 148, 149, R10
- IP rating: IP68
- Connector type: 2-pin Deutsch DTP
- Mating connector: Yes
- Cable length: 50 cm
- Shape: Round 9”
- Dimensions: 220 × 205 × 74 mm (Width|Height|Depth) ((Height with stand: 217 mm))
- Weight: 2.6 kg
- LEDs: 16 x LED
- Light output control (boost): Yes
- Mounting: Bottom-mounted stand
- Warranty (months): 24
