The Monsterlux Core 7 is a 7-inch round LED auxiliary light with modern dark optics, combining a powerful beam, a pleasant light pattern and a refined appearance. The light is designed for everyday use by drivers who value clear visibility, a stylish appearance and reliability without unnecessary complexity.
The balanced light pattern combines a long beam with wide-angle visibility, enhancing driving comfort even in challenging conditions. The 5000 K colour temperature provides natural and eye-friendly light, particularly in the dark, in the rain and in snowy conditions. Monster Mode™ unlocks the headlamp’s maximum performance for off-road use, significantly increasing both light output and beam range.
A durable body construction, hard-coated lens and IP68 protection make the Core 7 a reliable choice for year-round use. White and orange parking lights complete the modern look. The light is well suited to quad bikes, passenger cars, commercial vehicles and work machines, both as a pair of auxiliary lights and as part of a multi-light setup.
Technical specifications
● Product number: 3555-701001
● Make and model: Monsterlux Core 7
● Lumens: 5,134 lm (E-approved measurement) 7,513 lm (Monster Mode measurement)
● Beam range: 445 m (E-approved) 700 m (Monster Mode)
● Colour temperature: 5000 K
● Current consumption at 13.7 V: 2.8 A (E-approved) 9.8 A (Monster Mode)
● Operating voltage: 9–36 V
● Power: 38 W (E-approved) 134 W (Monster Mode)
● Reference number: 45
● Parking light: Yes, white and orange
● Road-legal: Yes
● Approvals: 148, 149, R10
● IP rating: IP68
● Connector type: Deutsch DTP 2-pin
● Mating connector: Yes
● Cable length: 50 cm
● Shape: Round 7”
● Dimensions: 171 × 159 × 73 mm (Width|Height|Depth) ((Height including stand: 171 mm))
● Weight: 1.6 kg
● LEDs: 12 x LED
● Light output control (boost): Yes
● Mounting: Bottom-mounted stand
● Warranty (months): 24
