General
• Product type: Motherboard - ATX
• Chipset type: Intel Q270
• Compatibility: Intel vPro
• CPU base: LGA1151 Socket
• Maximum number of processors: 1
• Compatible CPUs: (supports 6th and 7th generation Intel Core i3 / i5 / i7 / Pentium / Celeron / Xeon CPUs, maximum TDP 91 watts)
Supported RAM
• Maximum size: 32 GB
• Technology: DDR4
• Bus Clock: 2400 MHz, 2133 MHz
• Supported RAM integrity check: Non-ECC, ECC (works in non-ECC mode)
• Stored or Buffered: Unbuffered
• Features: Two-channel memory architecture, Intel Extreme Memory Profiles (XMP) 2.0, supported ECC modules operate in non-ECC mode
Audio
• Type: HD Audio (8-channel)
• Audio Codec: Realtek ALC897
• Compatibility standards: High Definition Audio
LAN
• Network controller: Intel I219V
• Network connections: Gigabit Ethernet
Extension / Connectivity
• Expansion slots:
1 x CPU
2 x DIMM 288-pin
1 x PCIe 3.0 x16
12 x PCIe 3.0 x1
• Memory connections: SATA-600 connectors: 4 x 7pin SATA, 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5
• Connections:
4 x USB 2.0
1 x audio line input - mini jack
1 x audio line output - mini jack
1 x microphone - mini jack
2 x USB 3.2 Gen 1
1 x PS/2 keyboard
1 x PS/2 mouse
1 x HDMI
• Internal connections:
1 x set - header
1 x speaker - header
2 x USB 3.2 Gen 1 - header
2 x USB 2.0 headers
1 x audio header
• Power connectors: 24-pin main power connector, 8-pin ATX12V connector, 2 x 4-pin auxiliary power connector
Characteristics
• BIOS type: AMI
• BIOS features: Multilingual BIOS, UEFI BIOS, SMBIOS 2.7 support, ACPI 6.0 support
• Hardware monitoring: Central unit core temperature, body temperature, CPU fan speedometer, case fan speedometer, system voltage, CPU core voltage (core voltage), power supply fan speedometer
• Sleep / Wake up: LAN wake up (WOL, wake on LAN)
• Hardware features: 15µ Gold Contact, 6 Phase Power Design, Intel Turbo Boost Technology 2.0, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, Sapphire Black PCB, ASRock Live Update, Premium 45A Power Choke, Intel Active Management Technology (Intel AMT) 11.6
Change
• Included accessories: I/O back panel, 1 x M.2 screw
• Included cables: 2 x Serial cable ATA
• Included software: Drivers and utilities, Antivirus (trial version), Google Chrome Browser, Google ChromeToolbar
• Compatibility standards: FCC, EuP Ready, ErP Ready, HDCP 1.4
• Width: 30.5 cm
• Depth: 20.8 cm
