General
• Product type: Motherboard - ATX
• Chipset type: Intel Z590
• CPU base: LGA1200
• Maximum number of processors: 1
• Compatible processors: (supports 10th and 11th generation Intel Core)
Supported RAM
• Maximum size: 128 GB
• Technology: DDR4
• Bus Clock: 2666 MHz, 4800 MHz (OC), 4666 MHz (OC)
• Supported RAM integrity check: Non-ECC, ECC (works in non-ECC mode)
• Stored or Buffered: Unbuffered
• Features: Two-channel memory architecture, Intel Extreme Memory Profiles (XMP) 2.0, supported ECC modules operate in non-ECC mode
Audio
• Type: HD Audio (8-channel)
• Audio codec: Realtek ALC897
• Compatibility standards: High Definition Audio
LAN
• Network controller: Dragon RTL8125BG
• Network connections: 2.5 Gigabit Ethernet
Extension / Connectivity
• Expansion slots: 1 x CPU, 4 x DIMM 288-pin, 2 x PCIe 4.0 x16 (double: x16, x4 mode; single card: x16 mode; PCIe 4.0 (11th generation Intel processors), PCIe 3.0 ( 10th generation Intel processors), 3 x PCIe 3.0 x1, 1 x M.2 (Key E)
• Memory connections: SATA connectors: 6 x SATA - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 4.0 connectors: 1 x Hyper M.2, SATA-600 / PCIe 3.0 connectors: 2 x Ultra M.2
• Connections: 2 x USB 2.0, 1 x audio line-in, 1 x audio line-out, 1 x microphone, 2 x USB 3.2 Gen 1, 1 x PS/2 keyboard / mouse, 1 x HDMI, 1 x DisplayPort, 1 x LAN (2.5Gigabit Ethernet), 2 x USB 3.2 Gen 2
• Internal connections: 1 x Thunderbolt, 4 x USB 3.2 Gen 1, 1 x audio, 4 x USB 2.0, 1 x USB-C Gen 2x2
• Power connectors: 4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Characteristics
• BIOS type: AMI
• BIOS features: Multilingual BIOS, UEFI BIOS, SMBIOS 2.7 support, ACPI 6.0 support
• Hardware monitoring: CPU core temperature, chassis temperature, CPU fan speedometer, case fan speedometer, system voltage, CPU core voltage (core voltage)
• Sleep / Wake up: LAN wake up (WOL, wake on LAN)
• Hardware Features: ASRock Instant Flash, HDCP Compliant, 15µ Gold Contact, Supports AMD CrossFireX Technology, Supports AMD Quad CrossFireX Technology, ASRock Internet Flash, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment ( PXE), Supports Intel K-Series unlocked CPU, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Sapphire Black PCB, Dr.MOS MOSFET, Nahimic Audio Enhacer, ASRock Live Update, ASRock EZ Mode, Intel Optane Memory Ready, Premium 50A Power Choke, ASRock Steel Slots, 14 Phase Power Design, Intel Turbo Boost Max Technology 3.0, ASRock POST Status Checker (PSC), ASRock Full Coverage M. 2 Heatsink, ASRock Hyper M.2
Change
• Included accessories: I/O back panel, 4 M.2 screws, M.2 plug, ASRock video card holder
• Included cables: 2 x Serial cable ATA
• Included software: Drivers and utilities, ASRock A-Tuning, Antivirus (trial version), Google Chrome Browser, Google ChromeToolbar, ASRock Polychrome SYNC, ASRock Dragon 2.5G LAN Software
• Compatibility standards: FCC, EuP Ready, ErP Ready, DisplayPort 1.4, HDCP 2.3
• Width: 30.5 cm
• Depth: 24.4 cm
